Production Continues Uninterrupted in Winter! Laser Cutting Machine Maintenance Guide: Master These 4 Points for Unchanged Precision and Half the Number of Malfunctions

Winter's low temperatures and dryness pose a "hidden challenge" to laser cutting machines—ice in the water system can crack the laser tube, increased oil viscosity slows down transmission efficiency, and statically attracted dust can silently damage optical components. To ensure stable equipment operation and extend its lifespan, this targeted maintenance plan will help you easily cope with winter challenges!

I. Antifreeze is the Bottom Line: Protect the "Lifelines" of Water and Oil Systems

Low temperatures are most likely to cause water system malfunctions. Once the water tank freezes, it can lead to machine shutdown and repairs, or even direct damage to the laser tube and water pump. It is recommended to immediately drain the ordinary water from the water tank completely and replace it with industrial-grade antifreeze with a freezing point ≤ -20℃. Check the fluid level weekly to avoid poor circulation due to insufficient fluid.

Transmission components also require "warming": Low temperatures thicken lubricating oil, making guide rails and lead screws prone to jamming. It's necessary to promptly replace the lubricating oil with one suitable for low temperatures, and check oil pipes for hardening and cracking due to low temperatures, plugging any potential leaks in advance.

II. Moisturizing and Preventing Dryness: Optical Components Require "Delicate Care"

In winter, after turning on the heating, the humidity in the machine room often drops below 30%. The dry environment generates a large amount of static electricity, attracting dust to the laser lenses and reflectors, directly leading to decreased cutting accuracy and power loss. Before starting the machine each day, gently wipe the optical components with a lint-free cloth dampened with a special cleaning agent to remove dust and oil (be careful not to scratch the lenses); simultaneously, use a humidifier to control the humidity in the machine room at 40%-60%, creating a "comfortable environment" for the optical components.

III. Preheating and Inspection: Circuit Safety Cannot Be Ignored

The electrical system is prone to "malfunction" at low temperatures. Don't rush to start cutting each time you turn on the machine. First, power it on and preheat for 10-15 minutes, allowing the laser power supply and circuit board to stabilize at room temperature before operation, avoiding damage to components from sudden high-voltage impacts.

Weekly inspections of electrical wire connections are crucial: low temperatures can make wire sheaths brittle. Each power and signal cable, both internal and external, must be checked. If cracks in the sheath or loose connections are found, replace or reinforce them immediately to prevent short circuits and safety hazards.

IV. Material Pre-treatment: Details Determine Cutting Results

Materials are prone to shrinkage in winter. For example, acrylic and wood shrink and deform in low temperatures, making direct cutting prone to dimensional deviations and edge cracks. Before processing, let the materials sit in the machine room for 2-4 hours to allow their temperature to match the equipment environment, eliminating the effects of thermal expansion and contraction. Before leaving get off work each day, remember to clean the workbench of waste and residue to prevent metal shavings and dust accumulation, which can corrode the equipment or affect the positioning accuracy of the next operation.

Proper winter maintenance not only reduces equipment downtime but also extends the lifespan of core components such as laser tubes and guide rails, reducing later maintenance costs. If needed, I can customize a more detailed maintenance plan based on the specific equipment type (fiber optic/CO₂) or usage scenario, which can be printed and posted directly.
